| Type |
Powered Pallet Truck |
| Power Souce |
DC Motor |
| Condition |
new |
| Place of Origin |
Jiangsu China (Mainland) |
| Brand Name |
Jetstar |
| Model Number |
JST-CDD 15 |
| Rated Loading Capacity |
1500KG |
| Max. Lifting Height |
5500MM |
| Min. Lifting Height |
205MM |
| Fork Length |
1150MM |
| Fork Width |
160MM |
| Overall Dimensions |
1800*1000*2350 MM |
New- Electric Pallet Stacker (3300 lbs)Model: JST-CDD15 Electric Transport and Lift Pallets or Loads Securely and Economically.Compact Design Allows it to Pass Through Doors and Work in Heavily Congested Areas.Meets International StandardFeatures:Electirc Stacker Triple MastUnitJST-CDD 1 1KG=2.2LB 1INCH=25.4MMCapacitykg1500 Max.lifting heightmm5500 Load centermm600Turning radiusmm1650Standard fork L*W*H mm1150 × 180 × 70Driving|Lifting MotorKw1.2|2.2Battery & Charger210Ah (With External Charger)Travelling speed(load/unload)km/h4/6Lifting|lowering speed(load/unload)mm/s80/130 | 110/90Gradient(load/unload)%5/8Overall Size (L*W*H)mm2200 ×1000 × 2485Weightkg1300Braking typeElectromagnetic brakingControling typeSeries excited electric controller,stepless adjusting speed -Super-thin body and heavy duty design -Low noise,no pollution and reliable performance -Operating steady and flexible -large power separately excited motor -Howell type stepless adjusting speed -Emergency reverse function -Braking at no starting function -Regenerative braking function -Optional speed & working modes -Pressure compensation function -Low pressure alarming function Vehicle Limitations: Vehicle should not be used in the presence of flammable or explosive materials or in corrosiveenvironments (either acid and/or alkaline). Must be driven on a hard and level surface.Work ambient temperature should be no higher than +104°F (40°C) and not lower than -104°F (-25°C). Relative humidity should not exceed 50% when the ambient temperature reaches +104°F (40°C). Higher relative humidity is fine at lower temperatures.Vehicle is not rated for use above elevations of 1200m (3,937 ft).
